D2904/6000-01 |
上海东讯：www.hifi-efax.com
|
D2904/6000-01 |
上海东讯：www.hifi-efax.com
| Characteristic sensitivity (2.83V / 1m) |
:
|
90.5 dB | |
| Recommended frequency range |
:
|
2.5 - 20 kHz | |
| Free air resonance frequency, fs |
:
|
750 Hz | |
| DC resistance, Re |
:
|
3.5 ohm | |
| Voice coil inductance, Le |
:
|
0.02 mH | |
| Effective piston area, Sd |
:
|
8.0 cm2 | |
| Moving mass incl. air, md |
:
|
0.40 g | |
| Force factor, BL |
:
|
2.7 Tm | |
| Excursion, lin./max. |
:
|
±0.25 / ±1.3 mm | |
| Voice coil diameter |
:
|
28 mm | |
| Rated power handling |
:
|
150 W (12 dB/oct. | |
| cross-over at 2.7 kHz) | |||
| Net weight |
:
|
0.13 kg |
